Custom Made PCB Design 12v UPS Printed Circuit Board PCB

FOB Reference Price:Get Latest Price
  • 1 - 99 Pieces
    $0.50
  • >=100 Pieces
    $0.30
Report Suspicious Activity
Overview
Quick Details
Brand Name:
NOEYA
Model Number:
Customized
Base Material:
Aluminum Base
Copper Thickness:
0.3oz-4oz
Board Thickness:
0.2mm-5mm
Min. Hole Size:
0.20mm
Min. Line Width:
0.1mm
Min. Line Spacing:
0.075mm
Surface Finishing:
HASL Lead Free
Product name:
Aluminum pcb
Certificate:
ISO/UL/TS16949/RoHS/TS16949
Solder mask color:
green, white, black, red, blue, yellow, customized
silk screen color:
white, black, green, blue, red, customized
Min. solder mask dam width:
0.076mm
Min. SMT/QFP Pitch:
0.40mm
Min. BGA Pitch:
0.4mm
Supply Ability
Supply Ability:
500000000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
vacuum for inner package
carton for outer package
Port
Shenzhen

Custom Made PCB Design 12v UPS Printed Circuit Board PCB

Our Company

Welcome to Shenzhen Noeya Technology Ltd.



Noeya,founded in 2003, is  a professional manufacturer of double-sided and multilayer precision printed wiring boards.

It covers an area of 10,000 square meters and enjoys beautiful environment and convenient transportation.





With Professional management talents and more than 500 experienced employees (among whom 30% are engineers and technicians),

we can monthly yield 30,000~40,000square meters or more ,among which, 40% are exported to foreign countries.

Our products are  mostly applied to products such as industry control products,automobile elctronics,touch screen and new energy,

but also in communication equipment, computer, intelligence, home appliance, medical equipment, etc.



With the Complete management/sales/quality/after sales service system and the operation Philosophy of

“quality is our life, honesty is our soul and rate is our unchangeable pursuit”, we believe more professional service can be provided.

Our company has been certified to ISO9001:2008, ISO14001:2004, TS16949 and UL (E25943). Complete system and 10years+ production experience create stable quality.





And then, please look at thes main euipments!

High precision, High Quality!

Our Technological process

Our International Certificates

Some of our dear customers



Products Overviews

Noeya PCB products glance

Noeya PCB Capability

CapabilityStandardAdvanced
LaminateFR4, FR1, CEM-3, CEM-1, Aluminum, Rigid-Flex PCB, Teflon, High-TG, Rogers, Taconic
Surface Finish

HASL(vertical & Horizontal), Lead Free HASL

ENIG,ENEPIG

HASL+Gold Finger

OSP / Entek

Immersion Tin(ISN), Immersion Silver(IAG)

Carborn Ink

Hard Gold(Flash Gold), Soft Gold

Min. Thickness for inner layers0.020''-0.125''0.003''(0.07mm)
Board layers1-24 Layers1-24 Layers
Board Thickness0.1mm-3mm0.2mm-7mm
Copper weight0.5 oz-6 oz0.5 oz-8 oz
Minimum Trace Width/Spacing0.003''/0.003''0.003''/0.003''
Solder Mask ColorGreen, Blue, Black, Red, Yellow, White amd customized
Drill deviation0.004''

±0.002''(0.05mm)

PTH Hole Tolerance0.004''

±0.002''(0.05mm)

NPTH hole Tolerance0.008''

±0.002''(0.005mm)

Min. hole size0.004''0.008''(0.02mm)
E-testFlying Probe Tester/Test-Jig/X-ray/ICT/AOI/FCT
Controlled Tolerance

±3%

±3%

Silkscreen ColorWhite, Black, Yellow, Green, Red, Blue, and customized
Min. Solder Mask clearance size0.0080.003''(0.07mm)
Min. silkscreen clearance size0.010''0.06''(0.15mm)
IPC ClassClass 2Class 3
Blind ViasYESYES
Buried ViasYESYES
Aspect Ratio8/115/1
Carbon InkYESYES
Peelable MaskYESYES
Solder SampleYESYES
First ArticleYESYES
CertificateUL / SGS / ROH / ISO / TS16949 / ISO14001:2004
Acceptable file formatGERBER File, PROTEL 99 / PADS / POWER PCB / AutoCAD / EAGLE



Details of PCB & PCBA

Technical requirement for pcb&pcb assembly:

---Professional Surface-mounting and Through-hole soldering Technology
---Various sizes like 1206,0805,0603 components SMT technology
---ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
---PCB Assembly With UL,CE,FCC,Rohs Approval
---Nitrogen gas reflow soldering technology for SMT.
---High Standard SMT&Solder Assembly Line
---High density interconnected board placement technology capacity.



Quote requirement for pcb&pcb assembly:

---Gerber file and Bom list
---Clear pics of pcba or pcba sample for us
---Test method for PCBA



To get much more information about our products, Please click this link!https://szczpcb.en.alibaba.com/?spm=a2700.8239084.0.0.z4Dmds

Services

One-stop service and Full range of Pcbs

We offer flex, rigid, and flex-rigid PCBs up to 24layers.

Never mind to inquire us!

 Main Services

(1) We manufacture PCB,PCBA,Singe / Double side PCB, Multilayer PCB,Aluminium PCB,Spray Tin PCB,

      Immersed Gold PCB,HDI Mobilephone PCB,Gold-plating PCB,(printed circuit board with assembly) PCBA,

      SMT PCBA,DIP PCBA,PCB&PCBA Copy,PCB Assembly,OSP,HASL,etc.

(2) Expert circuit board testing, high quality factory wholesale price.

(3) PCB OEM&ODM Clone/Copy, conform to UL,SGS,Rohs.

Best electronics services

  • PCB Production Service. (FR-4,HI-TG,Aluminum,FPC,TEFLON,CEM-1 )
  • FPC,PCB Copy Service.
  • PCB Assembly Service. (SMT, BGA, DIP)
  • IC program with HEX file.
  • PCBA Housing assembly serivce.
  • PCBA Final Functional Testing.
  • PCBA Copy Service.
  • Electronic Components Purchasing & BOM List Purchasing Services.
  • PCB SMT Stencil. (Laser cut & Etching)

Trade assurance

Much higher quality products

6. Serious quality control system

 Your contents are always our Pursuit!

FAQ

1. Q:Which type of  PCBs do you expert in?

We specialize in producing HDI multilayer blind, BGA, impedance, half-hole, double-sided, single-sided, etc.

2. How many years of producing pcb and pcba experience do you have?

We are OEM on PCB and PCBA boards with experience over 12 years.

3. Q: What does Noeya need for a customized PCB order?

 We do pcb according to Gerber file. You also can send all the details of the products you need to us if you cannot offer the file.

4. Q: What does Noeya  need for a customized PCBA order?

 Gerber file and the BOM list to Noeya

5. Q:What is your testing policy and how you control the quality?

For sample, usually tested by flying probe; for PCB Volume over 3 square meters, usually tested by fixture, this will be more faster. Due to there’s many steps to PCB production, we usually do inspection after every step.

6. Q:PCB shipment?

This is in accordance to each customer's needs. Sometimes we ship through our forwarder, who is also the agency of DHL, TNT, UPS, Fedex, and so on. Our forwarder can provide too much better freight cost than we get directly from those express enterprise.

7. Q: Can you design gerber file?

We can design gerber file if customer can provide us schematic, schematic sample can also be provided if customer want.

8. Q: What material brand you use for your PCB?

KB, SL, NANYA, TACONIC, ROGERS and so on.

9. Q: What is your minimum order quantity?

We have no limitation on MOQ, prototype, medium volume and large volume are all acceptable.

10. Q: What is your produce ability?

Our ability is average 40,000 square meters per month.

11. Q: How about the service Noeya offered to the customers?

 If you have any questions about our products or company, do not hesitate to send us your inquiry to our customer service representatives. Your satisfaction is our pursuits.

 Any questions, please never hesitate to inquire us~
